SIKAFORCE 7550L15 BLACK IN 450 ML CARTRIDGE

SIKAFORCE 7550L15 BLACK - CARTRIDGE 450 ML

SikaForce 7550 L15 is an elastic, fast-curing and non-sagging assembly adhesive.

•

• Cold applied and highly thixotropic

• Short cut-off string

• Fast cure and strength development independent to air humidity

• Elastic/good gap-filling capabilities

• Adequate working time to complete assembly, despite rapid cure

• Bonds well to a wide variety of substrates

• Withstands high dynamic stresses

• Vibration damping

• Electrically non-conductive

• Ageing resistant

• Solvent- and PVC-free


•

• Suitable for structural joints that will be subjected to dynamic stresses, where rapid strength development and fast cure is an essential requirement

• Ideal for the adhesive bonding of large components and assemblies

• Suitable substrates are plastics and metals, particularly aluminium sheets, steel, metal primers and paint coatings (2-component systems), wood and ceramic materials


•

• Chemical base

  Comp. A (resin) : Polyols, filled

  Comp. B (hardener) : Isocyanate derivates, unfilled

• Curing mechanism : Polyaddition

• Colour

  Comp. A : Black

  Comp. B : Whitish

  Mixture A+B : Black

• Density (25°C) (CQP 553-1)

  Comp. A : 1.33 g/cm3 approx.

  Comp. B : 1.13 g/cm3 approx.

• Viscosity (25°C) (CQP 538-1 / DIN 53019)

  Comp. A : 25 000 mPas approx.

  Comp. B : 25 000 mPas approx.

• Viscosity mixed (CQP 536-1 / DIN 53019) : 170 000 mPas approx.

• Mixing ratio

  parts per weight : 100:42

  parts per volume : 100:50

• Application temperature : +15°C to +30°C

• Open time at +23°C and 50% r.h. (CQP 526-1) : 15 min approx.

• Tensile-shear strength (CQP 046-1 / ISO 4587) : 5 Mpa approx.

• Strength development and curing speed according tensile-shear strength at 23°C (73°F) / 50% r.h. (CQP 046-1 / ISO 4587)

  2 h : 0.20 Mpa approx.

  4 h : 0.45 Mpa approx.

  24 h : 1.80 Mpa approx.

• Shore-A-hardness (CQP 023-1 / ISO 868) at 23°C (73°F) / 50% r.h. : 70 approx.

• Tensile strength (CQP 036-1 / ISO 37) at 23°C (73°F) / 50% r.h. : 5 MPa approx.

• Elongation at break (CQP 036-1 / ISO 37) at 23°C (73°F) / 50% r.h. : 350% approx.

• Glass transition temperature (CQP 509-1 / ISO 4663) : -50°C approx.

• Electrical resistance (CQP 079-2 / ASTM D 257-99) : 1011Ωcm approx.

• Service temperature (CQP 513-1) (continuous) : -40°C to +90°C approx.
